FocusX - The fastest & most versatile measuring device in its class





Optical 3D measuring machine for "dimention, position, shape and roughness"

The FocusX is an optical 3D measuring machine that can handle all your measurement tasks – a high-resolution, high-repeatability device for measuring size, position, profile, and roughness, with data scanning capabilities. The FocusX is the most versatile optical 3D measuring machine in its class. Its applications are broad, ranging from highly reflective surfaces to steep flanks and complex geometries – small radii, sharp angles, and tight tolerances, even in large quantities, pose no difficulty for the FocusX.

The FocusX operates simply and efficiently. With just one click, users can quickly and easily obtain ISO-standard roughness measurements – all without requiring specialized knowledge.
The FocusX can provide millions of measurement points in just a few seconds, with high resolution and accuracy. The FocusX offers superior measuring performance in a smart and affordable device – welcome to the new era of precision measurement.







Six Reasons to Choose the FocusX







GENERAL SPECIFICATIONS

Thể tích vị trí (X x Y x Z): 200 mm x 200 mm x 180 mm = 7 200 000 mm³

Không gian vị trí (R x T): AdvancedReal3DUnit (optional): Motorized rotation: 360° / Motorized tilt: - 15° to + 90°



OBJECTIVE SPECIFIC FEATURES:

Objective name   1900 WD30 800 WD37 800 WD17 400 WD30 400 WD19 150 WD11 80 WD4
Working distance mm 30 37 17.5 30 19 11 4.5
Lateral measurement range (X,Y) mm 3.8 1.6 1.6 0.8 0.8 0.3 0.16
Measurement point distance µm 1.77 0.72 0.72 0.36 0.36 0.14 0.07
Measurement noise nm 80 40 15 20 5 2 1
Vertical resolution nm 250 130 50 80 30 15 10

Thông số độ phân giải và ứng dụng

Objective name   1900 WD30 800 WD37 800 WD17 400 WD30 400 WD19 150 WD11 80 WD4
Min. measurable roughness (Ra) µm n.a. 0.7 0.18 0.24 0.12 0.05 0.03
Min. measurable roughness (Sa) µm n.a. 0.35 0.09 0.12 0.06 0.025 0.015
Min. measurable radius µm 12 5 5 3 3 2 1



The benefits of the FocusX from fast measuring capability and high flexibility



Non-contact 3D measurement

Features with highly reflective surfaces, steep flanks, and complex geometries – all pose no problem for the FocusX! The optical measuring device determines precise form and position parameters as well as roughness data of components (e.g., knee implants) automatically, traceably, and repeatably. And of course, all of this is non-contact.





High-accuracy measurement

Have you ever tried to measure the size, position, form, and roughness of a milled and laser-machined component from machine tools like Kern Precision? Find out how Vertical Focus Probing Technology enables non-contact measurement of workpiece edges while also allowing the measurement of holes and bores with a diameter-to-depth ratio of 1:3 up to 1:10.





Access to every tight corner on the sample

In production, the 3D representation of components plays a crucial role. Imagine a measurement task on an electronic connector with a tab width of less than 10 mm and a tab thickness of less than 1 mm. With Real3D Technology, this component is measured from multiple angles, and the various visual images are merged into a full 3D data set.
